LDP Fluid Bed Coating Machine

Description
Fluid bed coating machine is a new type of granulating coating machine that combines fluidized coating technology with spray technology. With fluid bed coating machine, particles are fluidized and the coating fluid sprayed on and dried. Small droplets and a low viscosity of the spray medium ensure an even product coating.

Application
1.Fluid bed coating machine is ideally suitable for capsules, pills, granules and powder coating.
2.Fluidized bed coating equipment mainly serves to improve the general handling or storage times, i.e. time limited protection against moisture, oxygen or light.

Features
1.The production cost of fluid bed coating machine is low without any coating material losing.
2.The material dispersion of fluidized bed coating machine is excellent and there is no adhesion phenomena.
3.The line between fog particles and materials is short without any spray drying phenomena.
4.The products of fluidized bed coating equipment are capable of moisture-proof, anti-oxidation, water-proof and exothermal coating.
5.The bottom spray is fluidized and there is strict running truck for the materials and therefore uniform and continuous coat film can be produced.

Parameters of Fluid Bed Coating Machine

Model	LDP-3	LDP-5		LDP-15		LDP-30		LDP-60		LDP-90		LDP-120			LDP-200	LDP-300~1000
Feeding Amount (g/batch)	3	5		10-20		25-40		40-80		50-90		80-120			150-200	According to user requirements.
Container Capacity	12	22		50		100		220		300		420			650
Power of Fan	4	4		7.5		7.5		15		18.5		18.5			22
Noise	Isolation processing for the fan, noise ＜ 75db
Compressed Air Pressure (Pa)	0.6
Compressed Air Consumption	0.4		0.4		0.6		0.9	1.1	1.1		1.3		1.3
Steam Pressure	0.4 to 0.6
Steam Consumption (g/h)					64		85	181	210		250		330
Electric Heating Power	6		9		Determined by user requirements
Dimension of Main Engine (L × W × H) (mm)	850 × 770 × 2600		1000 × 750 × 2600		1550 × 1170 × 3230		1700 × 1460 × 3620	1800 × 1660 × 3720	1800 × 1760 × 3870		2000 × 2060 × 4100			2100 × 2260 × 4360

Founded in August, 2000, Jiangsu Yutong Drying Engineering Co.,Ltd. is a professional fluid bed coating machine manufacturer and granulating machine supplier in China. Yutong possesses 10 professional engineering and technical personnel and over 100 sets of processing equipment. Over the years, we make our effort to the development and production of fluidized bed coating machine, drying equipment, grinding machine and blending machine. With rapid development, we have already accumulated abundant capital and technology strength. Yutong has various experimental coating machines for customers to test and inspect.
